Breather Valve |
|
| |
A Breather Valve is a safety feature attached to a nozzle opening on top of storage tank with a fixed roof. The valve is one type of relief valve and its main function is to provide sufficient air to the storage tank when the tank is in an out-breathing condition |
|
| |
|
|
| |
Breather valves are low pressure device designed to protect tanks, recess systems and equipment from damage due to over pressure or vacuum. They are also know as pressure/vacuum relief valves. Breather valves retain toxic vapours thus preventing atmospheric contamination and increased fire protection and safety. Retention of vapour also minimizes production losses through evaporation.
Pressure/Vacuum relief valves are used extensively on bulk storage tanks, including fixed roof tanks with floating cover, to minimize evaporation loss. The valves prevent the build up of excessive pressure or vacuum that can damage the storage vessel. Pressure and vacuum protection levels are controlled with weighted pallets or spring and can be combined to provide the required pressure/vacuum setting. |
|
|
|
|
| |
|
|
| |
| Specifications |
Brand : FLOWTECH
Size : 50 TO 500 NB
Connection : Flanged/screwed
Mounting : Top
Material : CI/WCB/CF8/CF8M/Customized
Gasket : PTFE/CAF/NON-Asbestos
Fasteners : ASTM A 193 Gr B7-A194 Gr2H/SS304/SS316
Types of Breather Valve
Spring Loaded
Pilot Operated
Weight Loaded
Breather or Pressure/vacuum relief valves have weight loaded or spring loaded pallets .Flow through the valve is controlled by the weight of the pallet or the spring force acting on the palled to the device control.
|
|
|
|
| |
|
| |
| VALVES |
We are very much pleased to introduce ourselves as one of the manufacturer of Industrial
valves suitable for high performance, high temperature and highly corrosive fluid joints. We
manufacture and supply any type of Ball valves, Butterfly valves, Check valves, Actuated valves and Flushbottom valves of various materials.
We are supplying to Refineries, Petrochemical Industries, Gas Lines, Air Lines, Sugar, Equipmentmanufacturers, Power, Paper, Steel sectors and Pharmaceuticals in the name of Flowtech/SRK Valves.
We have established for ourselves as a business house with excellent turnover recognition in theglobal market by giving the best quality & service. Owing to our latest infrastructure, we manufacture awide range of Industrial Valves in different sizes and metals like brass, stainless steel, Monel and othermaterials as per the clients requirement. All our products are manufactured under stringent qualitycontrol.
Specifications
Brand : FLOWTECH
Size :15 TO 500 NB
Connection : Flanged/screwed
Material : CI/WCB/CF8/CF8M/Customized
Gasket : PTFE/CAF/NON-Asbestos
Fasteners : ASTM A 193 Gr B7-A194 Gr2H/SS304/SS316
|
|
VALVES |
|
|
| |
|
|
| |
| Emergency Relief VALVES |
Emergency Relief Valves are fitted to storage tanks to allow emergency flow due to the excessive venting requirement from a fire burning around a storage tank. This eliminates a costly tank rupture, providing emergency venting from abnormal internal pressure beyond the capability of the pressure relief vent. In the event of a fire, the pallet will lift at a pre-determined pressure, thus creating a large venting area.
A PTFE/EPDM insert is provided to achieve leak tight sealing between the pallet and seat under normal operating conditions. An alternative model is available, fitted with an additional spring-loaded vacuum valve that will open under negative pressure to protect the tank from any damage that may occur under vacuum conditions.
Specifications
Brand : FLOWTECH
Size : 50 TO 900 NB
Connection : Flanged
Mounting : Top
Material : CI/WCB/CF8/CF8M/Customized
Gasket : PTFE/CAF/NON-Asbestos
Fasteners : ASTM A 193 Gr B7-A194 Gr2H/SS304/SS316
Types of Emergency Relief Valve
• Spring Loaded
• Weight Loaded
|
|
Emergency Relief VALVES |
|
|
| |
|
|
| |
|
|
| |
